Haskel 86991 Hydrogen Gas Booster
NOTE: this is a version of the AGT-14/62 modified for HYDROGEN service.
Features & Benefits:
- Reliable, easy to maintain, compact and robust
- No heat, flame or spark risk
- Infinitely variable cycling speed and output
- Pneumatic driven units do not require electrical connections
- Easy to apply automatic controls
- No limit or adverse affect to continuous stop/start applications
- Seal systems designed for long working life
- No air line lubricator required
- Hydrocarbon free – separation between air and gas sections
- Built-in cooling (most models)
- Suitable for most gases
- Ability to stall at any predetermined pressure and hold the fixed pressure without consuming power or generating heat
Technical Data:
- 1st Stage Ratio: 14:1
- 2nd Stage Ratio: 62:1
- Min GAS supply pressure: 25 psi
- Max GAS supply pressure: 4 Pa to 2500 psi
- Max rated GAS outlet pressure: 9000 psi
- Static outlet stall pressure formula: 60 Pa + 4 Ps (Pa = air drive pressure; Ps = gas supply pressure)
- Min AIR drive pressure: 20 psi
- Max AIR drive pressure: 150 psi
- Interstage relief valve? N/R
Sample Performance Characteristics:
- Boost 5.8 SCFM Hydrogen Gas from 250 psi to 4000 psi using 48 SCFM Air @ 100 psi supply pressure
Physical Characteristics:
- Unit weight: 41 lbs.
- Displacement / cycle: 13.2 cu./in.
- Max cycles: 60/min.
- GAS inlet/outlet connections: 3/8″ FNPT inlet & Interchangeable 3/8″ SAE or 1/4″ HP outlet
- AIR drive inlet port: 1/2″ FNPT
Haskel 86991 Hydrogen Booster Repair Kit information:
- Gas section seal kit P/N: 29344-1 AND 87017 AND 86690
- Air drive section seal kit P/N: 87094
- Air valve seal kit P/N: 17329
- Check valves seal kit P/N: 17325
- Distance piece kit P/N: N/A
- Optional tools: 28584 (Sleeve removal tool); 16675 (Wrench for gas booster check valve seats); 17246 (Wrench for gas booster piston nut)
- Notes:
- P/N 29344-1 kit includes the piston and check valve seals (-14 side).
- P/N 87017 Gas Section kit covers the entire gas section, including the piston seals (-62 side).
- P/N 86690 kit includes the piston seals only (-62 side).
- P/N 17325 kit includes the check valve seals only (-62 side).
Optional Modifications:
- C-8: Air filter, regulator with gauge, and manual start/stop
- 17860: Electrical stroke counter
- 25721: Mechanical stroke counter
- 29376: Three-way cycling spool
- 29702: Single-stroke modification
- 50341: Low permeability seals for CO2 gas service
- 51050: Extreme service cycling modification
- 54827: Level II cleaning and certification of gas sections
- 56611-2: Vent purge with 15 psi relief
- 57875: Panel with regulator for mounting remote APS
- 59888: Cycle timer
- 80862: Viton air drive seals
- 82500: ATEX modification
- 86337: Extended life air drive seals
To add any modifications to this booster or for assistance in selecting the right booster for your application, please contact our Sales Department for assistance.
